| Models | KSM-2000X | KSM-1000X |
| Image Device | 1/3" B/W Sony EXview HAD CCD | |
| DeepThru™ Technology | Installed | |
| X-Ray Vision Format | Always B/W X-Ray Images | |
| Pixels | 410,000 | 270,000 |
| Scanning | 2:1 Interlace | |
| Sync System | Internal | |
| Resolution | 570 TV Lines | 400 TV Lines |
| Video Out | 1.0 Vp_p (COMPOSITE) | |
| S/N Ratio | More than 45dB (AGC OFF) | |
| Minimum Illumination | 0.003 Lux at F1.2 | |
| Day/Night Function | IR Cut Filter Removed | |
| Lens Mount | C/CS | |
| Gamma | 0.45 | |
| Shutter Speed | 1/60~1/100,000s (EIA), 1/50~1/100,000s (CCIR) | |
| Power Supply | Regulated DC 12V | |
| Current Consumption | Max.145mA | |
| Operating Temperature | -10℃~50℃ | |
| Storage Temperature | -20℃~60℃ | |
| Dimensions | 45(W)Ⅹ40(H)Ⅹ113(L)mm | |
| Weight | Approx. 200g | |
