Lynceus™ XHD-7000 Full HD Camcorder with IR X-Ray Vision(See-Through Vision) & IR Night Vision
XHD-7000 X-Ray Vision Off (7.9km Mountain Fog)
XHD-7000 X-Ray Vision On (7.9km Mountain Fog)
XHD-7000 X-Ray Vision Off
XHD-7000 X-Ray Vision On
XHD-7000 IR Night Vision Off
XHD-7000 IR Night Vision On
XHD-7000 IR Night Vision Off
XHD-7000 IR Night Vision On

Lynceus™ XHD-7000  Key Features

  • Near Infrared Enhanced CMOS Sensor
  • IR X-Ray Vision(See-Through Vision) Technologies, KAYA's Proprietary System
  • Kaya 37mm PF2 filter (for outdoor usage) and PF4 filter (for indoor usage) included
  • Infrared Night Vision Technologies (5 feet distance)
  • Normal Color Vision, X-Ray Vision(See-Through Vision), Infrared Night Vision Easily Selectable
  • Powerful Auto Focus in Color, X-Ray Vision(See-Through Vision) and Night Vision Modes
  • Full HD 1080p (1920 x 1080) video capture (30 fps)
  • Ultra High Quality 60 frames per second at 720p HD mode
  • JPEG still pictures up to 16MP image resolution
  • 1700 mAH Rechargeable Lithium-ion battery
  • Multiple Ports: HDMI, SDHC Card, Micro SD Card, USB 2.0
  • Wide 3" (16:9) Touch Screen LCD
  • Industry standard H.264 - AVI format
  • Tripod mount
  • Supports up to 64GB (Max 32GB in each SD Card slot)
  • 100X Super Zoom (10X optical zoom and 10X digital zoom)
  • Timer shooting
  • Motion detection
  • Pre-recorded

Buy It Now

Lynceus™ XHD-7000  Specifications

Image Sensor 1/3.2" Near Infrared Enhanced CMOS sensor
Effective Pixels  5.0 Mega Pixels (2592 x 1944)
Storage Media  Supports SDHC, up to 32GB class 4 or above
Memory 32MB (1Gbits NAND Flash)
Lens 10X Optical zoom lens
f=4.6mm~46mm (35-350mm, 35mm equivalent)
Focus Range Wide: 10cm~Infinity / Tele: 90cm~Infinity
Movie Clip Resolution: Full HD (1920 x 1080) at 30fps / HD (1280 x 720) at 30fps and 60fps
Playback Function: Play/Pause, Forward, Rewind
Slow Motion On: 1/2X ~ 1/64X
Slow Motion Off: 2X ~ 64X
Still Image Resolution:
16M (4608x3456, by interpolation)
12M (4000x3000, by interpolation)
8M (3200x2400, by interpolation)
5M (2592x1944)
Format: DCF 1.1 (JPEG, Exif2.2)
Playback:10X digital zoom
TFT Screen 3.0" Touch Panel screen (16:9)
Assist Lamp White LED: 1m effective distance
IR LED: 1m effective distance
Shutter Electronic shutter, Auto:1/2 ~1/2000 sec, Night: 2~1/2000 sec
Exposure  Average, Center, Spot
ISO Movie mode: Auto
Still image mode : Auto (100-400), 100, 200, 400, 800, 1600, Auto800(100-800), Auto1600(100-1600)
Interface Mini B Type USB 2.0 (high-speed)
Mini C Type HDMI
Microphone Yes
Speaker Yes
Battery 1700mAH Lithium-ion rechargeable
Operating Temperature 0° ~ 40°C
Operating Humidity 20 ~ 70% RH
Dimensions  122.5 x 56.5 x 63 mm
Weight Approx. 320g


Included Accessories

Buy It Now

IR X-Ray Vision(See-Through Vision) Cameras, Camcorders, Lens, Glasses, Filters Reveal the Hidden World!
IR X-Ray Vision meets many application needs in such diverse applications as security, surveillance, forest survey, documents inspection and camouflage detection. Kaya Optics, Inc. produces IR X-Ray Vision glass/gelatin filters and camera systems that see beyond the visible wavelength spectrum.

IR X-Ray Vision Cameras See Through Fog, Mist, Haze, Rain, Snow, Smog, Dust and Sand

IR X-Ray Vision Cameras See Through Fog, Mist, Haze, Rain, Snow, Smog, Dust and Sand

IR X-Ray Vision Cameras See Through Dark Sunglasses

IR X-Ray Vision Cameras See Through Tinted Windows

IR X-Ray Vision Cameras See Through Envelope, Paper and Playing Cards

IR X-Ray Vision Cameras See Through Ink

DeepThru™ Vision Technology is KAYA's groundbreaking technology that produces high fidelity See-Through Vision. Surpassing the capabilities of conventional ccd cameras, DeepThru™ Vision Technology provides the superior see-through image quality and absolute performance using the Real-time Digital Fog Reduction Algorithm together with the IR X-Ray Vision. Lynceus™ Long Range Camera Systems based on the cutting edge DeepThru™ Vision Technology provide the ability to see through fog, mist, haze, rain, snow, smog, dust, sand, dark sunglasses and tinted car windows up to miles away.
The Lynceus™ series of camera systems is an exciting revolutionary advancement in surveillance solutions. This series features Long Range Day & Night See-Through Vision, Long Range Night Vision with IR Laser Illuminator, Long Range Thermal Imaging and Long Range Assessment. This series is ideal for airport, border, transportation, port, and nuclear facility, petrochemical, critical infrastructure, or homeland security applications.
Above video was taken by the Lynceus™ See-Through Vision Dome Camera DDA-1000 model and showing Normal Color Vision and IR X-Ray Vision simultaneously
